LC-12 HD LCD Digital Camera (2.0MP) and Viewer

LC-12 HD LCD Color Digital Camera (2.0MP) and Viewer) is a revolutionary product in microscope area which combines of tablet PC and a digital camera, it can preview, take snaps, videos and save them, wireless transmission, 3G internet surfing. It has a C-mount connecter which can be connected to any microscope with microscope adapters. It is an Ideal instrument of industrial optical inspection, teaching and scientific research.

Labomed, Inc. is certified by ISO 9001-2013, has CE Conformity and is FDA Licensed.


Features

  • Specially designed and optimized for All-in-one. Microscope with LCD pad for Preview, capture photo & video, storage, playback, wireless Data Network, etc.

  • High quality images, true color as same as CCD cameras.

  • Easy to install. Come with a international standard C-mount connector, it can be installed on monocular, binocular, trinocular, stereo, dissecting and various kinds of microscopes and telescopes with optional eyepiece adapter (microscope adapter), which  includes  0.5x  eyepiece adapter(Φ23mm), Φ30mm and Φ30.5mm connecting rings.

  • Wide View Angle, Adjustable 90° Inclined.

  • Abundant data output, convenient for transmission. Come with Mini USB, TF Card Slot, External 3G, HDMI interface, Headphone Slot, Microphone and Power supply slot.

  • Built-in Android 2.2 Operating System, Complete Application Functions. Users can download any of the tens of thousands of Android application software from the official Android Market and other websites. High quality entertainment (pictures, movies, music, reading and games) is just a finger swipe away.

  • . 7" LED Backlight HD LCD Screen. 4 points Multi-touch screen, gravity sensor.
  • Powerful web functions, keep you connected with friends, family and clients. Wireless Wi-Fi transfer and optional 3G internet access allows users to be connected to internet, Share the information via Email, MSN, Forum, Blog, access online services any time wherever you go.

  • Aluminum C-mount connector, solid and reliable connection.


Top of the Page

Application

LC-12 HD LCD Color Digital Camera (2.0MP) and Viewer can be used in Education, Industry, Medical and R&D areas for HD teaching, academic demonstration; precision electronic assembling and QC; biological, medical, pharmaceutical, geologic, mineral, metallurgical and chemical research.

Technical Specifications

Digital Parts

2 MegaPixels, 1/3 " CMOS Sensor, 1600×1200

Image-previewing Rate: 15 fps at Full Resolution

Connection: C-mount or Ocular Tube adapter

Display

7" LED Backlight LCD Screen (800×480)

G-sensor, Multi-point Capacitance Touch Screen

Operating System

Android 2.2

CPU

A8, 800MHz

RAM

512MB DDR2-400

Storage Device

4G Flash, Support External TF Card, Maximum Capacity of 16GB

Application Software

Photo/Video/Browser/Reset/Task/Calculator/Calendar/Clock/Dairy/Emails/Book/E-book/Music/Games/MSN/Skype/Gmail etc.
System Software Support Various Android, Download from Android Market

Buttons

Top Button: Turn on/off, Volume+, Volume –, Reset

Front Main Button: Return, Home, Menu, Search

Battery

Capacity: 3800mAh, Rechargeable Li-Polymer Battery
Work time with 1 recharge: 10hours

Wi-Fi

Support Wireless Data Network, Wireless lan 802.11b/g

3G Network

Optional 3G Module to Realize 3G Communication, Support EVDO/WCDMA/TD

Interface

1×Mini USB2.0, 1×HDMI, 1×Micro-SD Card Slot (Up to 16GB), 1×3.5mm Headphone Slot

Audio

2×Built-in CLASS-D Digital Power Amplifier Loudspeaker, Built-in Microphone

Media File

Photo File Formats Support: JPG, JPEG, BMP, GIF, PNG, TIFF

Video File Formats Support: MKV (h.264hp), AVI, RM, RMVB, FLV, MPEG-1, MPEG-2

Language

Multi Language (T-, S- and English etc.)

Adapter

DC5V 2500mA, Plug Type Optional: USA , EU, UK and Japan etc.

Accessories

Power Adapter, USB Cable, User Manual

Operating Temperature

-30°C to +70°C

Includes 0.5x Microscope Adapter (eyepiece adapter) 23mm
30mm connecting ring

Sample Images
