LC-7 USB2.0 CCD Color Digital Camera (1.4MP)

LC-7 USB2.0 CCD Color Digital Camera (1.4MP) are CCD cameras. Real scientific CCD sensors are adopted and images and videos can be captured with high sensitivity and low image noise. With USB2.0 interface, C-mount, LC-7 CCD cameras can be used for high precision image analysis of low light, bright field, dark field, fluorescence in life science and industrial applications. Microscope adapter and connecting rings can be chosen to connect the digital cameras to any microscopes.

Labomed, Inc. is certified by ISO 9001-2013, has CE Conformity and is FDA Licensed.


Features

  • Real scientific-grade Color/mono CCD image sensor with high sensitivity and low image noise, no compression, no interpolation;
  • Perfect image quality and high dynamic range with the perfect detail;
  • High speed image preview and fast focus;
  • High-speed USB2.0 interface, up to 480Mb/s;
  • Supports uncompressed, compressed videos:
  • Provides completed API for users’ Secondary development, provide Demo Source Code;
  • Hardware automatic gain control (AGC) and Exposure Control (AEC);
  • Software auto white balance, auto exposure, continuous auto exposure control;
  • Users can program to control white balance and exposure area;
  • Supports the plug recovery during acquisition and preview;
  • Supports firmware upgrade on-line;
  • C-mount, 0.5X microscope adapter and 30mm, 30.5mm connecting rings are optional;
  • Plug and play, dispense with external power supply;
  • Supports Windows XP / Vista / 7 Operation System;
  • Supports VC, VB, DELPHI, LABVIEW and other development language;
  • Attaches the USB cable on the camera with bolt, the USB cable cannot fall off;
  • Supports Directshow and Twain;
  • Supports standard C-mount lenses and all kinds of customized lenses;
  • Durable aluminum alloy shell.

Top of the Page

Applications

LC-7 USB2.0 CCD Color Digital Camera (1.4MP) are mainly used for high precision quantitative analysis in low light, brightfield, darkfield, fluorescence imaging of life science and industrial applications. These cameras also can be used in a Machine Vision area.

Technical Specifications

Model

LC-7

Description

USB2.0 Color CCD 1.4MP digital camera

Image Sensor

1/2 inch, Color 1.4MP Sony CCD ICX205AK

Pixel Size

4.65μm×4.65μm

G Sensitive

400mV

Spectral Response

400nm~1000nm

Scan Mode

Progressive Scan

Exposure Mode

Electronic rolling shutter

Max Resolution

1360H × 1024V

Frame Rate

7fps@1360×1024

Lens Interface

Standard C-mount

Low-speed Readout

Yes

White Balance

Auto / Manual

Exposure Control

Auto / Manual

Exposure Time

1ms~60sec

Image Output

USB2.0, 480Mb/s

Power

USB2.0 Power Supply, 500mW

Parameters Control

Image size, Contrast, brightness, R.G.B gain, exposure time

Software Function

Image display, image processing, video

Working Temperature

0°C~60°C

Storage Temperature

-20°C~70°C

Working Humidity

10-90%

Accessories

Include C-mount, 2.0 meter USB cable, 1 CD with software and SDK., Manual

Camera Net Weight

200g

Camera Dimension

62mm×62mm×45mm (length × width × height)

Box Dimension

118mm×108mm×96mm (length × width × height)

Shell Dimensions

Module Dimensions

Sample Images
