Labomed Inc.




LB-232 Binocular Biological Microscope (Anti-Fungus) with Wide Field and Phase Contrast Kit

With precision machining equipment and advanced alignment technology, LB-232 Binocular Biological Microscope (Anti-Fungus) with Wide Field and Phase Contrast Kit are precise biological microscopes.

Labomed Inc. is certified by ISO 9001, CE Conformity and is FDA Licensed.


Features

  • New machining facility and advanced alignment technology;
  • With complete functions and outfit of binocular microscope;
  • Comfortable operation with updated and ergonomic design;
  • Compact and flexible, ideally suited for desktop, laboratory worktable;
  • Interpupillary distance can be adjusted to fit for observation.

Top of the Page

Technical Specifications

Applications

LB-232 Binocular Biological Microscope (Anti-Fungus) with Wide Field and Phase Contrast Kit is an ideal instrument in the biological, histological, and pathological fields and can be widely used in medical and sanitary establishments, laboratories, institutes, academic laboratories, colleges and universities.

Viewing Head

Binocular Head, Head Binocular sliding inclined at 45 º and 360 º turn 55-75mm interpupillary distance. Anti-mould.

Eyepiece

Wide Field Eyepiece WF10×/ 18

Nosepiece

Quadruple Nosepiece

Objective

Achromatic Objective 4×, 10×, 40×, 100×
(Can be supplied with plan achromatic objectives)

Total magnifications

With 10x eyepiece: 40×, 100×, 400×, 1000×

Stage

Double Layer Mechanical Stage 140×140mm/ 75×50mm

Focus

Coaxial Coarse & Fine Adjustment, Moving Range 28mm, Fine Division 0.002mm. Coarse Stroke 37.7 mm per rotation.

Condenser

Abbe NA 1.25 with Iris Diaphragm & Filter

Illumination

LED Illumination

Plan-concave Mirror
Kohler illumination (optional)

Body / Energy

Body firm backing of Aluminum and built in power supply 110-240V

Supplied with

Dust cover, green filter, immersion oil and operating manual

Dimension & G.W.

33cm×28cm×44cm×, 9 kg

Sample Images

The following specimen images are taken with LB-232.

Phase Contrast Kit

With Phase Contrast Kit, after installing and aligning it, you can:

  • Observe living bacteria and cells.
  • Observe achromatic and transparent specimens which are unable to view in normal Bright Field.
  • Observe the specimen in different magnifications without any additional adjustment.�

ALL ACCESSORIES ARE OPTIONAL AND MUST BE ORDERED SEPARATELY

click here to fill out the Information Request Form
