LB-120 Polarizing Monocular Microscope
LB-120 Monocular Polarizing Microscope is specifically designed for geology, minerals, metallurgy, university teaching laboratories and other sectors. It also can be used in chemical fiber industry, semiconductor industry and the pharmaceutical inspection industry. Digital camera can be used together with the microscope for image analysis.
Labomed Inc. is certified by ISO 9001, CE Conformity and is FDA Licensed.
|
Eyepiece |
Eyepiece WF10×/18 with scale of cross hair |
Eyepiece WF10×/18 with graticule |
|
Eyepiece WF10×/18 |
|
Eyepiece WF5×/20 |
|
Objective |
Strain free achromatic objective 4×, 10×, 25×, 40×, 63× |
Bertrand Lens |
Bertrand lens, Sliding in/out of optical path |
Optical Compensator |
λ Slip (first class red), 1/ 4λ Slip, Quartz wedge |
Revolving Round Stage |
Diameter Φ130mm, Graduated in 1° increments, Minimum resolution 6' when using vernier scale |
Condenser |
NA1.25 Abbe condenser with iris diaphragm & filter |
Polarizer |
360° Rotatable, Located on the top of collector |
Illumination |
6V/20W Halogen lamp, Brightness adjustable (Transmitted illumination) |
Accessories |
Micrometer 0.01mm |
Blue filter |
ALL ACCESSORIES ARE OPTIONAL AND MUST BE ORDERED SEPARATELY
