Labomed Inc.




LB-122 USB Digital Microscope

LB-122 USB DIgital Microscope provides powers from 10× to 200× with 2.0MP Image sensor (interpolated to 5MP). It is ideally suited for Medical, Industrial Inspection, Engineering, educational and Science Applications to examine coins, stamps, rocks, relics, insects, plants, skin, gems, circuit boards, various materials and many other objects. A rugged, metal stand is included for holding the microscope steady at various positions for viewing and/or imaging. With the included software, you can observe the magnified images, capture video, take snapshots and do measurement with Windows Win7, Win 8, Win 10 32 bit & 64 bit, Mac OS X 10.5 or above Operating systems.

Labomed Inc. is certified by ISO 9001, CE Conformity and is FDA Licensed.

Features

  • Easy to use portable digital microscope with USB output interface.
  • 10× to 200× Magnification.
  • 2.0 Mega Pixels CMOS sensor, interpolate to 5MP with software.
  • Manual Focus from 10mm to 500mm.
  • LED illumination with 8pcs LED lamps, brightness adjustable.
  • Photo management software, Auto White Balance and Exposure.
  • Powered by USB 2.0 cable, 5V DC.
  • Metal stand to hold the microscope steady.
  • Multi-language support: English, Germany, Spanish, French, Russian.
  • Operating System: Windows Win7, Win 8, Win 10 32 bit & 64 bit, Mac OS X 10.5 or above.

Top of the Page

Technical Specifications

Applications

LB-122 USB Digital Microscope can be used for: Hobbyists, Educators, Medical Labs, Industrial Inspection, Engineering Applications, Teachers, Students, Science Applications, Doctor’s Offices, Police Agencies, Government Testing, and general use by consumers. It is ideally suited for examining solid objects such as coins, stamps, rocks, relics, insects, plants, skin, gems, circuit boards, various materials, and many other objects.

Image Sensor

2.0 Mega Pixels CMOS sensor (interpolated to 5MP)

Capture Resolution

2560×2048(5MP), 2000×1600, 1600×1280(2MP), 1280×1024, 1024×960, 1024×768, 800×600, 640×480, 352×288, 320×240

Focus Range

Manual Focus From 10mm to 500mm

Frame Rate

Max30f/s under 600 Lus Brightness

Magnification Ratio

10× to 200×

Video Format

AVI format

Still Image Format

JPEG or BMP

Light Source

8 LED adjustable by control wheel

PC Interface

USB 2.0

Power Supply

5V DC from USB port

Operation System

Windows Win7, Win 8, Win 10 32bit&64 bit, Mac OS X 10.5 or above

OSD Language

English, German, Spanish, French, Russian

Bundled Software

MicroCapture with measurement & calibration function

Size

110mm(L) × 33mm(R)

Weight

160g

Package Content

Digital microscope with USB cable, Metal Stand, User Manual, CD with Software

Packing Info

Gift box, 20pcs/carton, 8.2kgs/carton, carton size: 45.5×34.5×30.0 cm

Sample Images

ALL ACCESSORIES ARE OPTIONAL AND MUST BE ORDERED SEPARATELY

click here to fill out the Information Request Form
