LB-276 Binocular Biological Microscope

with Infinite Optical System, Wide Field,

Infinite Plan Achromatic Objectives (4x, 10x, 20x, 40x, 100x)

LB-276 Binocular Biological Microscope with Infinite Optical System, Wide Field, Infinite Plan Achromatic Objectives (4×, 10×, 20x, 40×, 100×) is high level microscopes which is specially designed for college education, medical and laboratory study. It adopts an Infinite optical system, beautiful structure and ergonomic design. With an innovative optical and structure design, excellent optical performance and easy to operate system, these biological microscope make your works enjoyable.

Labomed, Inc. is certified by ISO 9001, CE Conformity and is FDA Licensed.

Features

1. Excellent infinite optical system with high resolution and perfect definition.
2. Wide field 10×/Φ22mm eyepiece, more comfortable for observation..
3. 100X water objective is available for convenient viewing.
4. Trinocular head with light distribution 100:0 (100% for eyepiece) and 80:20(80% for trinocular head and 20% for eyepiece).
5. Rackless stage is is safer than traditional stage.
6. Various accessories for upgrading.


Top of the Page

Technical Specifications

Applications

LB-276 Binocular Biological Microscope with Infinite Optical System, Wide Field, Infinite Plan Achromatic Objectives (4×, 10×, 20x, 40×, 100×) is an ideal instrument in biological, histological, pathological, bacteriology, immunizations and pharmacy field and can be widely used in medical and sanitary institutes, such as hospitals, clinics, academic laboratories, colleges and universities.

Specification LB-276
Optical System Color Corrected Infinite Optical System
Viewing Head Seidentopf Binocular Head, Inclined 30°, Rotatable 360°, Interpupilary Distance: 48-76mm
Eyepiece WF10×/22mm (Diopter adjustable), tube diameter: 30mm
Infinite Plan Achromatic Objective 4×/0.10,            W.D.=12.10mm
10×/0.25,           W.D.=4.64mm
20×/0.40(S),         W.D.=2.41mm
40×/0.65 (S),        W.D.=0.65mm
100×/1.25(S, Oil),    W.D.=0.12mm
Nosepiece Backward Quintuple Nosepiece
Stage Rackless Double Layers Mechanical stage, Size: 182mm×140mm, Travel Range: 77mm×52mm, Scale: 0.1mm, Two Slide Holder
Condenser Swing out condenser N.A.0.9/0.13, with iris diaphragm
Focusing Coaxial Coarse and Fine Focusing Knob, Coarse Focusing Travel Range: 25mm, Coarse Stroke 42.4mm/rotation, Fine Stroke 0.2mm/Rotation, Fine division: 2µm
Koehler Illumination 6V/30W Halogen Lamp with Field Diaphragm, Brightness Adjustable
Video Adapter 1× C-mount (Used for DSLR cameras or large format microscope camera)
0.5× C-mount (focus adjustable, used for microscope camera)
Photo Adapter Used for CANON/NIKON/OLYMPUS/ SONY DLSR cameras
Filter Blue
Power Supply Wide voltage input: 100V~240V
Packing 1 carton/set, Packing Size: 565mm × 310mm × 410mm, Gross Weight: 12 kgs, Net Weight: 10 kgs





Sample Images

ALL ACCESSORIES ARE OPTIONAL AND MUST BE ORDERED SEPARATELY
