LB-208 Fluorescent Biological Binocular Microscope with Achromatic Objective 4×, 10×, 40×, 100×

LB-208 Fluorescent Biological Binocular Microscope with Achromatic Objective are basic level microscopes which are specially designed for college education, medical and laboratory study. They have beautiful structure and ergonomic design. The excellent optical performance will make your works enjoyable.

Labomed Inc. is certified by ISO 9001, CE Conformity and is FDA Licensed.


Features

  • Excellent fluorescent image with high resolution fluorescent objectives.
  • Protect the light leak with advanced lamp housing.
  • Perfect image with fluorescent objectives.
  • More stable power supply, digital display and timer.

Top of the Page

Technical Specifications

Application

LB-208 Fluorescent Biological Binocular Microscope with Achromatic Objective are ideal instrument in biological, histological, pathological, bacteriology, immunizations and pharmacy field and can be widely used in medical and sanitary establishments, clinics, hospitals, laboratories, institutes, academic laboratories, colleges and universities.

Item Specification
Viewing Head Sliding Binocular Viewing Head, Inclined at 45°, 360° Rotatable, Interpupillary distance 55-75mm, Anti-mould
Eyepiece Wide Field Eyepiece WF10×/18mm, Eyepiece Tube Diameter 23.2mm
Objective Achromatic Objective 4×, 10×, 40×, 100×
  Fluorescent Achromatic Objective 4×, 10×, 40×, 100×
Nosepiece Quadruple Nosepiece
Focusing Coaxial Coarse & Fine Adjustment, Fine Division 0.002mm, Coarse Stroke 37.7mm per Rotation, Fine Stroke 0.2mm per Rotation, Moving Range 28mm
Stage Double Layer Mechanical Stage 140×140mm, Cross Travel 75×50mm, Can Hold Two Sides
Condenser Abbe Condenser NA1.25 with Iris Diaphragm & Filter
Reflected Light Source   Excitation Dichroic Mirror Barrier Filter
Blue Excitation BP460~490 DM500 BA520
Green Excitation BP510~550 DM570 BA590
Lamp 100W HBO Ultra Hi-voltage Spherical Mercury Lamp
Power Box Power box NFP-1, 220V/ 110V Interchangeable, Digital Display
Transmitted Illumination 1W S-LED illumination, Brightness Adjustable
Optional Accessories Photo Attachment, Video Attachment, Polarization Set, Phase Contrast Kit, Dark Field Attachment
Package 2cartons/set, 33cm*28cm*44cm, 7kg; 38*45*26cm, 5kg



Sample Images

LB-208 Sample 1

LB-208 Sample 2



ALL ACCESSORIES ARE OPTIONAL AND MUST BE ORDERED SEPARATELY
