LC-35 - 5MP USB2.0 Graphics Accelerated Microscope Camera

PDF Brochure

With Innovative customized ISP technology, the LC-35 - 5MP USB2.0 Graphics Accelerated Microscope Camera’s frame rate has been greatly improved. The frame rate of uncompressed original imaging is 5MP@22fps. This series digital cameras provide simple and economical microscopy imaging. They are widely used in academic and medical fields for precision and high resolution microscope image capturing and processing.

Labomed Inc. is certified by ISO 9001, CE Conformity and is FDA Licensed.

Top of the Page

Technical Specifications

Model	LC-35
Sensor Model	Sony, IMX335LQN-C
Sensor Size	1/2.8"
Resolution	5MP, 2560x1920
Pixel Size	2.0 μmx2.0μm
Frame Rate	22fps
Color/Mono	Color
Shutter Type	Rolling Shutter
Exposure Mode	Auto/Manual
Picture Format	TIFF/JPG/PNG/DICOM
Operating System	Windows 7/8/10 (32 Bit/64 Bit)
PC Software	Capture 2.0
SDK	C/C++, C#, Directshow
Optical Interface	C-Mount
Data Interface	USB2.0
Operating Temperature	0-60℃
Operating Humidity	10%-85%
Camera Size	68X68X42.5(mm)
Camera Weight	253g
Note:	Capture 2.0 software does not support the dark field image processing module, real-time image  stitching and real-time depth of field fusion function module when it is used with LC-35 cameras.





Sample Images

Diatom-Inverted Fluorescent Microscope-4x

Bright Field 20x

Mosquito 5.0MP

Polarizing Slide
