LC-16 HDMI 1080P High Resolution

Digital Camera (6.0MP, 30fps)

LC-16 HDMI 1080P High Resolution Digital Camera (6.0MP, 30fps) is a camera that can take picture, take videos and make measurements. It also have a good resolution and color.

LC-16 HDMI 1080P High Resolution Digital Camera (6.0MP, 30fps) is a 1080P scientific grade digital camera that has ultra superior color reproduction and super fast frame speed.

LC-16 HDMI 1080P High Resolution Digital Camera (6.0MP, 30fps) can be connected to a LCD monitor or HD TV via HDMI cable and operated independently without connecting to PC. The image/video capture and operate can be controlled by mouse, so no shaking when you take images and videos. It also can be connected to a PC via USB2.0 cable and operate with the software.

With fast frame speed and short responding time features, LC-16 HDMI 1080P High Resolution Digital Camera (6.0MP, 30fps) can be used in many areas like microscopy imaging, machine vision and similar image processing fields.

Labomed Inc. is certified by ISO 9001, CE Conformity and is FDA Licensed.


Features

  • Built- in mouse control Camera.
  • Record image and video to SD card.
  • High frame rate upto 60fps.
  • HDMI Fluorescent imaging Capability.
  • Functions inside camera (Cloud 1.0)
    1. Simple to operate
    2. Set Exposure Time Capability
    3. 3D Noise Reduction
    4. 1080P Video Recording
    5. Get more Details with ROI Magnification Function
    6. Image Comparison Function
    7. Browse Captured Images
    8. Measurement function when it is connected to LCD monitor
    9. PC software



Technical Specifications

Application

LC-16 HDMI 1080P High Resolution Digital Camera (6.0MP, 30fps) can be widely used in video conferencing, remote medical diagnosis, microscopy images, industrial inspection, video projectors, security monitoring field. With the high image quality and easy to operate features, it will be your best assistant for following applications:

  • Live Cell Imaging
  • Surgical Microscopic Imaging
  • Pathology
  • Cytology
  • Defect Analysis
  • Semiconductor Inspection
  • Metrology
  • Navigation for Processed Imaging
  • Industrial Optical HD Digital Imaging
  • Astronomical Observation

Model

LC-16 HDMI 1080P High Resolution Digital Camera (6.0MP, 30fps)

Image Sensor

Colorful Sony IMX236 CMOS Sensor

Chip Size

1/2.8"

Pixel Size

2.8um × 2.8um

Video Resolution

1920 × 1080

Captured Image Resolution

3264 × 1840 on SD card to LCD monitor,
1920 × 1080 and 3264 × 1840 with software to PC

Preview Frame Rate

1920 × 1080 30fps via  USB2.0
1920 × 1080 60fps via  HDMI

Data Record

High speed SD Card (8G)

Video Record

1080p 30fps @ SD Card
1080p 30fps @ PC

Scan Mode

Progressive

Electronic Shutter

Electronic Rolling Shutter

A/D conversion

8 bit

Color Depth

24bit

Sensitivity

510mV

Dynamic Range

68dB

S/N ratio

52dB

Exposure time

0.001 sec ~ 10.0 sec

Exposure

Automatic & Manual

White balance

Automatic

Settings

Gain,Gamma,Saturation,Contrast, scale bar function

Measurement Function when connected to LCD Monitor

Complete measurement function, including Anchor Point, Line, Freehand Line, Rectangle, Circle, Polygon, Point-line Distance, Concentric Circles, Bicircle, Angle etc.

PC software

ISCapture

Output model 1

USB2.0

Output model 2

HDMI

System Compatible

Windows XP/Vista/Win 7/8(32 and 64-bit ), MAC OSX

Optical port

C- Mount

Power Supply

DC 12V /2A

Working Temperature

0-60°C

Humidity

45%-85%

Storage Temperature

-20-70°C

Dimension & Weight

78*70.8*90.7mm, 1kg

Sample Images





click here to fill out the Information Request Form
