LC-21 HD LCD Color Microscope Tablet Camera (5.0MP)
and Viewer

LC-21 HD LCD Color Microscope Tablet Camera (5.0MP) and Viewer is a brand new high performance and highly cost-effective, super reliable 9.7inches smart digital microscope tablet camera! Equipped with 5MP color COMS sensor and 9.7 inch tablet, it is developed specifically for microscopy applications. Along with an Android 4.2 operating system, it runs smoothly and the user experience is fantastic. With built-in professional software, including multi-functional measurement software and particle analysis software, the operation is very simple and efficient. Online upgrades are available, even if you are not proficient on the computer, you can independently accomplish all of the software upgrades! With a flexible configuration and wide application range, it is easy to achieve all of your desires of exploring and discovering the mystery of the microscopic kingdom.

Labomed, Inc. is certified by ISO 9001-2013, has CE Conformity and is FDA Licensed.


Features

  • Complete Application Functions, Not Only Camera, also Tablet PC!
  • 5 Megapixel color camera.
  • 9.7inch 1024 × 768 IPS Color LCD touchscreen, can be operated by USB keyboard and mouse.
  • Built-in Android 4.2 operating system, RK3066 dual-core 1.5GHz CPU.
  • Support external SD memory card.
  • Multiple interfaces, USB, SD Memory Card, HDMI Output can connect with monitor or projector screen.
  • WI-FI and Bluetooth ready.
  • Build-in microscopy software for capture images, record videos and make measurement.
  • Professional particle analysis software.
  • Measure data can be export to Excel file.
  • Standard C-mount Interface.

Top of the Page

Application

LC-21 HD LCD Color Microscope Tablet Camera (5.0MP) and Viewer can be used in many applications, including:

  • Biological Teaching Digital Imaging
  • Medical Digital Imaging Microscopy
  • Field Operation Digital Microscopic Imaging
  • Family Natural Science Education
  • Surgical Microscopic Imaging
  • Navigation for Processed Imaging
  • Industrial Optical HD Digital Imaging
  • Astronomical Observation

Technical Specifications

Hardware

CPU

RK3066 dual-core 1.5GHz

Display

9.7inch Color LCD Touch (1024*768)

Storage

RAM 1GB DDR3

ROM 2GB

Support External SD Memory Card, Maximum Capacity Up to 32GB

Camera

1/2.5” (4:3), 5Mega Pixel(2592H × 1944V) Color CMOS Sensor

15fps@1024 × 768

Network

WI-FI

Bluetooth

I/O

USB/Mini-USB (OTG), Support USB Keyboard and Mouse

HDMI Output

SD Memory Card Slot

DC5V Power Supply

On/Off Button

Mechanical

LCD Screen 360°@Horizontal/ 90°@Vertical

Software

Operating System

Android 4.2

Banding Software

Build-in Microscopy Software (Measuring and Particle Analysis)

Accessories

Standard

Power Adapter, USB Cable, User Manual

Optional

0.5× Nose Piece with Φ23mm, Φ30mm and Φ30.5mm Adapter Rings for
Different Diameter Eyepiece Holders.

Built-in Camera

Optical Format

1/2.5-inch (4:3)



Active Image Size

5.70mm(H) × 4.28mm (V)

7.13mm(Diagonal)

Active Pixels

2592H × 1944V

Pixel Size

2.2um × 2.2um

Dynamic Range

66.5dB

SNR

40.5dB

A/D Converter

12-bit, On-chip

Sensitivity

0.53V/lux-sec(550nm)

Resolution & Frame Frequency

1280 × 720@15fps

640 × 480@30fps

Shutter

Electronic Rolling Shutter (ERS)

White Balance

Auto/Manual

Easy to Install
Equipped with international standard C-type interface, it can be conveniently thread on both C-mount coupler and eyepiece adapter.
It is compatible with the monocular, binocular, trinocular and any kind of microscopes, such as stereo, video, dissecting microscope or telescopes.

Connect video coupler to the device

1. Remove the dust cover and lens protection film , then connect the C-Mount coupler to the device.



2. Install the device on microscope.

Power Supply
Optional Plug Types: USA/ EU/UK and Japan.

Connect one end of DC adapter cable to the power port at the bottom of the device, and the adapter to 100-240V AC power outlet.

Built-in Microscopy Software

After the device is turn on, touch the “YWCamera” Icon to open the camera application.

Real-Time Measurement Software

    1. Preview Image – show live video of the camera.
    2. Tool Panel – Control panels, capture, adjust parameter, measurement, etc.
    3. Thumbnail Panel – Show captured images and videos, touch it to browse the files.
    4. System Tool – Switch Camera, full screen, configure.

Particle Analysis Software

Touch the “YWImage” icon to open the particle analysis application.
