LB-126 LCD USB Digital Microscope
LB-126 LCD USB digital microscope provides powers from 20× and 300× with 5.0MP Image sensor, the LCD screen is 3.5inch. It can take images and videos and save in the micro
SD card. It also can be connected to PC and take image, take video and do measurement with
software. It is ideally suited for Medical, Industrial Inspection, Engineering, educational and
Science Applications to examine coins, stamps, rocks, relics, insects, plants, skin, gems, circuit
boards, various materials and many other objects.
Labomed Inc. is certified by ISO 9001, CE Conformity and is FDA Licensed.
- Can work independently, portable and easy to operate.
- 20× and 300× Magnification.
- 3.5 inches LCD screen, resolution 320×240.
- Images and videos can be saved in micro SD card, up to 32G.
- 5.0 Mega Pixels CMOS sensor.
- Manual Focus from 10mm to 50mm.
- LED illumination with 8pcs LED lamps, brightness adjustable.
Application
LB-126 LCD USB digital microscope can be used for: Hobbyists, Educators, Medical Labs,
Industrial Inspection, Engineering Applications, Teachers, Students, Science Applications,
Doctor’s Offices, Police Agencies, Government Testing, and general use by consumers. It is
ideally suited for examining solid objects such as coins, stamps, rocks, relics, insects, plants,
skin, gems, circuit boards, various materials, and many other objects.
Model
LB-126
Image Sensor
5.0 Mega Pixels CMOS sensor (interpolated to 12.0MP)
LCD Screen
3.5 inches LCD screen, resolution 320×240
Capture Resolution
12M, 9M, 5M, 3M, 1.3M, VGA
Focus Range
Manual Focus From 10mm to 50mm
Frame Rate
Max30f/s under 600 Lus Brightness
Magnification Ratio
20× to 300×(Digital Magnification can be 1200× )
TV output
Available to any monitor with TV in
Card Slot
Support MicroSD Card(not included) slot up to 32GB
Light Source
8 LED adjustable by control wheel
Battery
Rechargeable lithium battery (recharged by power adapter or USB)
Measurement
By software when connected to PC
OSD Language
English, German, Spanish, French, Russian
Bundled Software
MicroCapture with measurement & calibration function
Microscope Size
149mm(L)*104mm(W)*227(H)
Weight
1100g
Package Content
Microscope, Power Adapter, USB cable, TV cable, CD with Software, User’s manual
Packing Info
Gift box, 6pcs/carton, 9.0kgs/carton, 43.5x41.5x35cm
Sample Images
ALL ACCESSORIES ARE OPTIONAL AND MUST BE ORDERED SEPARATELY
